Description
About
Body & Door: Multi-layered structure that combines outer and inner steel plates enclosing a monolithic casting of specialized concrete mixed with ISM's unique anti-penetration composite material. The door is reinforced with ISM's patented anti-penetration alloy grid, providing high protection against concentrated attacks with mechanical and electrical tools.
Bolts & Locking Mechanisms: Three-way active boltwork. Double-action locking mechanism. Glass plate relocking protection on all locks.
Interior Fitting: Adjustable removable shelves. A hole for an alarm system connection - optional.
Locks: Two UL approved locks. Mechanical or digital combination lock and a high security key lock.
Security
Glass Plate Relocking Protection
Reinforced Bolt Cylinders
4-way Bolt Engagement
Special Alloy Grid
Double Locking Protection
Models
| Model | Inside Dimensions* | Outside Dimensions* |
Volume |
Weight | Shelves |
| H x W x D | H x W x D | Cu. Ft. | lbs. | ||
| BU251816 | 25" x 18" x 16" | 31.5" x 24.5" x 27" | 4.2 | 1,230 | 1 |
| BU352120 | 35" x 21" x 20" | 41.5" x 27.5" x 31 | 8.5 | 1,820 | 1 |
| BU352420 | 35" x 24" x 20" | 41.5" x 30.5" x 31" | 9.7 | 1,940 | 1 |
| BU452120 | 45" x 21" x 20" | 51.5" x 27.5" x 31" | 10.9 | 2,160 | 2 |
| BU452420 | 45" x 24" x 20" | 51.5" x 30.5" x 31" | 12.5 | 2,300 | 2 |
| BU552120 | 55" x 21" x 20" | 61.5" x 27.5" x 31" |
13.4 | 2,500 | 3 |
| BU552420 | 55" x 24" x 20" | 61.5" x 30.5" x 31" | 15.3 | 2,660 | 3 |
| BU602120 | 60" x 21" x 20" | 66.5" x 27.5" x 31" | 14.6 | 2,670 | 3 |
| BU602124 | 60" x 21" x 24" | 66.5" x 27.5" x 35" | 17.5 | 2,910 | 3 |
| BU652818 | 65" x 28" x 18" | 71.5" x 34.5" x 29" | 19 | 3,270 | 4 |
| BU723626 | 72" x 36" x 26" | 78.5" x 42.5" x 37" | 39 | 4,710 | 4 |
* Weight Tolerance - 5%.
** Dimensions Tolerance - ±0.5’’.
*** Add 2’’ to outside depth for 3-Spokes Operating Handle.
**** Add 3.55’’ to outside depth for Pull-Handle.
Colors
RAL 9010, RAL 7040, RAL 7016, RAL 9005
